The Red Single Sided Duct Tape now offers free sample testing services to global customers, with online inquiry and bulk purchasing options. With a monthly production capacity of 900,000 square meters, standard orders are delivered within 15 working days. The product has passed SGS testing and meets RoHS environmental standards. We provide professional technical support and customized services.
| Substrate specifications | |
| Material | High-strength PE woven fabric |
| Thickness | 0.25mm ± 0.02mm |
| Weight | 120g/m² ± 5% |
| Color | Eye-catching red (RAL 3020) |
| Adhesive properties | |
| Type | High performance acrylic pressure sensitive adhesive |
| Initial tack | 16-20 steel balls |
| Adhesion | ≥72 hours |
| 180° peel strength | ≥22 N/25mm |
| physical property | |
| Tensile strength | longitudinal ≥120 N/cm |
| Extension rate | ≤25% |
| Unwind force | 4-8 N/25mm |
| Tear strength | ≥100 N/cm |
Feature Performance
The eye-catching red makes it easy to identify and classify
Colors are long-lasting and fade-resistant
Improve safety alerts
Advantages of Substrate Properties
PE substrate waterproof and moisture-proof
High tensile strength and good durability
Excellent flexibility and adaptability to curved surfaces
resistance to chemical attack
Adhesive Advantages
Strong initial adhesion for quick positioning
Reliable adhesion and strong bonding
Weather resistance is stable
Convenience
Good unfolding force and easy operation
Easy to tear, high construction efficiency
Adapt to various construction environments
1. Substrate Preparation Process
raw material preparation:
High-density PE pellets
Red masterbatch (RAL 3020)
inhibitor
Weaving process:
Evenly woven grid lines
Density control 20×18 roots/cm²
Heat setting
afterfinish:
Surface leveling
Split and Roll
quality inspection
2. Adhesive Preparation
Raw material system:
Acrylate copolymer
Viscosity-increasing resin
Functional Additives
Synthesis process:
emulsion polymerization
Temperature control 85±2℃
Solid content 58±2%
3. Coating Process
Substrate pretreatment:
Corona treatment (5.5kW)
Preheat to 60°C
single spread:
Squeegee coating process
Coating weight 22±2g/m²
Coating speed 30-40m/min
Drying and curing:
Five-stage oven
Temperature: 70℃/90℃/110℃/90℃/70℃
Hot air circulation drying
4. Subsequent Treatment
Mature:
Mature at 50℃ for 24 hours
Humidity control 50±5%
Cut and pack:
High-precision slitting system
Automatic visual inspection
Dust-proof packaging
| standard specifications | |
| Thickness | 0.25mm ± 0.02mm |
| Width | 24mm/36mm/48mm/60mm/72mm |
| Length | 50m per roll (standard) |
| Inner diameter of coil | 76mm |
| technical parameter | |
| Base weight | 120g/m² |
| Coating thickness | 0.05mm |
| Initial tack | 16-20 steel balls |
| Unwind force | 4-8 N/25mm |
| performance index | |
| Tensile strength | ≥120 N/cm |
| Adhesion | ≥72 hours |
I. Warning Signs and Safety Protection Areas
Construction site: Mark dangerous areas (such as high-altitude work areas, live areas), temporary barriers, and fire escape signs. The red color has strong visual impact and can be quickly identified from 3 meters away, improving the effect of safety tips.
Industrial workshop: Temporary warning signs (e.g., "Do Not Operate", "Under Maintenance"), pipeline hazard level markings, and safety passage divisions, suitable for rough floors and equipment surfaces.
Public areas: temporary construction warning signs in shopping malls and office buildings, elevator maintenance barriers, and parking area signs in red, eye-catching and not easy to fade, suitable for crowded scenes.
2. Decoration and Exhibition Layout
Decoration construction: color separation and masking during wall and floor painting (clear red boundary to avoid color mixing of paint), temporary fixation and alignment positioning after wallpaper and tile laying.
Exhibition / Stage setup: Fixed posters, banners, backdrop boards, balloon arches and other props. Strong tensile strength can bear certain weight, and easy to tear and remove, without damaging the exhibition site wall.
Decorative elements: Securely fasten ribbons and attach decorative props at wedding and celebration venues. The red color harmonizes with the festive atmosphere while ensuring both structural stability and visual appeal.
3. Home and Civil Areas
Home repair: temporary fixation and anti-slip adhesive for the edge of sofa, curtain and carpet. Red Single Sided Duct Tape can be used as decoration and at the same time to solve the problem of loosening.
Storage organization: organize and fix wires and data cables in wardrobes and storage rooms. Red makes it easy to locate cables quickly and keep the environment clean.
Outdoor scenarios: The tent, canopy, and moisture-proof mat are securely fastened during camping. They are resistant to light rain and wind erosion, suitable for rough surfaces like grass and rocks, and are not easily broken when pulled.
Q1: What is the special role of red?
A: The eye-catching red color serves as a warning, making it easier to identify and manage.
Q2: Will the color fade?
A: Color fastness grade 4 or above, with color retention exceeding 90% after 800-hour UV testing.
Q3: Storage conditions?
A: Avoid high temperature exposure, store at room temperature and dry.
