The Yellow Single Sided Duct Tape now offers free sample testing services to global customers, with online inquiry and bulk purchasing options. Certified by SGS and compliant with RoHS environmental standards, we provide technical support and customized solutions.
| Substrate specifications | |
| Material | High-strength PE woven fabric |
| Thickness | 0.25mm ± 0.02mm |
| Weight | 120g/m² ± 5% |
| Color | Yellow |
| Adhesive properties | |
| Type | High performance acrylic pressure sensitive adhesive |
| Initial tack | 16-20 steel balls |
| Adhesion | ≥72 hours |
| 180° peel strength | ≥22 N/25mm |
| physical property | |
| Tensile strength | longitudinal ≥120 N/cm |
| Extension rate | ≤25% |
| Unwind force | 4-8 N/25mm |
| Tear strength | ≥100 N/cm |
| environmental performance | |
| Operating temperature | -30℃ to 70℃ |
Alerting Performance Advantages
Eye-catching yellow with high visibility
Complies with the International Safety Color Standard
Improve the effect of on-site safety warning
Facilitates area division and identification
Advantages of Substrate Properties
PE substrate waterproof and moisture-proof
High tensile strength and good durability
Excellent flexibility and adaptability to curved surfaces
resistance to chemical attack
Adhesive Advantages
Strong initial adhesion for quick positioning
Reliable adhesion and strong bonding
Weather resistance is stable
Convenience
Good unfolding force and easy operation
Easy to tear, high construction efficiency
Adapt to various construction environments
1. Substrate Preparation Process
raw material preparation:
High-density PE pellets
Yellow masterbatch
inhibitor
Weaving process:
Evenly woven grid lines
Pressing after heat setting:
Surface leveling
Split and Roll
quality inspection
2. Adhesive Preparation
Raw material system:
Acrylate copolymer
Viscosity-increasing resin
Functional Additives
Synthesis process:
emulsion polymerization
Temperature control 85±2℃
Solid content 58±2%
3. Coating Process
Substrate pretreatment:
Corona treatment (5.5kW)
Preheat to 60°C
single spread:
Squeegee coating process
Coating weight 22±2g/m²
Coating speed 30-40m/min
Drying and curing:
Five-stage oven
Temperature: 70℃/90℃/110℃/90℃/70℃
Hot air circulation drying
4. Subsequent Treatment
Matured:
Mature at 50℃ for 24 hours
Humidity control 50±5%
Cut and pack:
High-precision slitting system
Automatic visual inspection
Dust-proof packaging
| standard specifications | |
| Thickness | 0.25mm ± 0.02mm |
| Width | 24mm/36mm/48mm/60mm/72mm |
| Length | 50m per roll (standard) |
| Inner diameter of coil | 76mm |
| technical parameter | |
| Base weight | 120g/m² |
| Coating thickness | 0.05mm |
| Initial tack | 16-20 steel balls |
| Unwind force | 4-8 N/25mm |
| performance index | |
| Tensile strength | ≥120 N/cm |
| Adhesion | ≥72 hours |
1. Warning Signs and Safety Protection Areas
Construction site: mark the working area, temporary passage, pit warning, and mechanical operation range. Yellow is visually eye-catching and can be quickly identified from a distance to reduce construction safety risks.
Public scenarios: temporary construction barriers in shopping malls, schools and hospitals, elevator maintenance warnings, floor anti-slip reminders, safety guidance in crowded areas, and improved penetration of warnings.
2. Zone Identification and Management Area
Warehousing logistics: Warehouse goods are classified and zoned (such as inspection area, qualified goods area, return area), shelf number identification, inventory batch labeling, yellow is easy to distinguish, improve the efficiency of warehouse management.
Transportation hub: parking space zoning, temporary parking guidance, loading and unloading area signage, and flow guidance routes for stations and airports to help maintain order.
3. Decoration and Exhibition Layout
Decoration construction: color separation and masking during wall and floor painting or tile laying, with clear yellow boundaries to avoid color mixing of paint, and temporary fixation of decorative materials (such as baseboard and decorative panel).
Exhibition/Event Setup: Features durable fixtures including fixed posters, backdrop panels, display stands, and balloon decorations. Designed for high-frequency installation and removal, these components are easy to remove without damaging the venue.
Decorations: The yellow color is suitable for temple fairs, carnivals and other events. It is used for fixed ribbons, lanterns and theme decorations to balance beauty and stability.
4. Home and Civil Areas
Home repair: anti-slip fixing of carpet edge, temporary repair and adhesive of curtains and sofa covers. Yellow can be used as decoration, which combines practicality and beauty.
Storage organization: Categorize and label items in wardrobes and storage rooms, organize and secure power cords. Use Yellow Single Sided Duct Tape for quick identification and maintain a tidy environment.
Q1: What is the special meaning of yellow?
A: Yellow is the international warning color, which means attention and warning.
Q2: Which substrate surfaces are applicable?
A: Metal, concrete, wood, plastic and other materials.
Q3: Is customization available?
A: Support width, length and other specifications customization.
