The Green and White Warning Tape is specifically designed for environments with stringent environmental and safety requirements, including medical facilities, office spaces, and emergency exits. We now offer free sample testing to global customers, with online inquiry and bulk purchasing options. Our services include professional technical support and customized solutions.
| Substrate specifications | |
| material quality | PVC |
| Thickness | 0.13mm ± 0.02mm |
| Color | Green and white diagonal |
| Width | 48mm/72mm/96mm (customizable) |
| physical property | |
| Tensile strength | ≥48 N/cm |
| Extension rate | ≤170% |
| Adhesion | ≥10 N/25mm |
| Unwind force | 2-6 N/25mm |
| environmental performance | |
| Operating temperature | -15℃ to 60℃ |
| Weather resistance | up to 6 months for outdoor use |
| Ultraviolet resistance | color retention>85% after 400 hours of test |
| Security features | |
| Environmental certification | Passes RoHS testing and contains no heavy metals |
Safety Guide Advantages
The design is green and white, the internationally recognized safety color, and the indication is clear
The color is soft and suitable for sensitive places such as medical and office
Optional reflector model to improve nighttime visibility
Environmental Performance Advantages
Made with eco-friendly materials and RoHS certified
Low odor, suitable for sensitive indoor environments
Convenience
Low rolling resistance, easy construction
Medium viscosity, no residue after removal
Can be torn by hand directly and is easy to use
Quality Assurance Advantage
SGS certification ensures reliable quality
Good color consistency and batch uniformity
Provide complete after-sales service
Economic and Practical Advantages
High cost performance and low operating costs
Fast construction and labor saving
Service life meets requirements
I. Substrate Preparation Process
Material ratio: Precise ratio of PVC and additives
Rolling forming: precision rolling controls thickness
Cooling and setting: The cooling roller set ensures dimensional stability
II. Coating Printing Process
Undercoating: micro-embossed coating technology
Pattern printing: high precision four-color printing
Surface treatment: environmental protection film process
3. Solidify the Cutting Process
Curing and hardening: temperature zoning control
Cut and roll: automatic cutting and packaging
Quality control: whole-process quality control
| Standard length | 25m/45m/60m |
| Inner diameter of coil | 76mm |
| Packaging specification | 24 rolls/box |
| technical parameter | |
| Substrate thickness | 0.13mm ± 0.02mm |
| Total thickness | 0.16mm ± 0.03mm |
| Initial tack | steel balls of size ≥12 |
| Adhesion | >24 hours |
Medical Facility
Emergency lane sign
Medical Area Division
Epidemic Prevention Zone Instructions
Administrative Area
Safety Passage Sign
Work Area Division
Emergency facility instructions
Communal Facilities
Emergency escape route
Secure Group Area
Public signage
Industrial site
Secure Area Division
Emergency Equipment Identification
Evacuation route signs
Other Apps
Fire escape signage
Emergency exit guide
Safety facility signage
Q1: How long can it be used outdoors?
A: The Green and White Warning Tape is designed for 6 months of normal outdoor use. For special environments, it is recommended to shorten the replacement cycle appropriately.
Q2: Is it suitable for indoor use?
A: It is especially suitable for indoor use, low odor, environmentally friendly and safe.
Q3: What should we pay attention to during construction?
A: Keep the surface clean and dry, with ambient temperature above 10℃. Press firmly after application.
