1. Barrier Performance
Bubble wrap film has a unique bubble layer structure. It can effectively absorb impacts. It also has excellent puncture resistance, so it provides comprehensive protection for products. It has good resilience too, and it maintains protective effects for a long time.
2. Usage Advantages
Bubble wrap film is lightweight and easy to carry. It is simple to operate. You can cut it freely, so it has strong adaptability to different scenarios. It has a self-adhesive design, which makes it easy to stick and fix.
3. Quality Advantages
Bubble wrap film uses high-quality raw materials, so its performance is stable. It adopts advanced production technology, and its bubbles are uniform in size. It undergoes strict quality control, so its quality is reliable.
| Category | Item | Specification |
| Basic Features | Material | Polyethylene (PE) |
| Thickness | 0.5-2.0mm | |
| Bubble diameter | 6mm/10mm/20mm/30mm | |
| Color | Transparent | |
| Performance Parameters | Buffering performance | Impact absorption ≥80% |
| Puncture resistance | ≥300N | |
| Tensile strength | ≥12MPa in longitudinal direction and ≥10MPa in transverse direction | |
| Special Performance | Antistatic type | Surface resistance 10⁶-10¹¹Ω |
| Operating temperature | -30℃ to 70℃ |
| Standard Specifications | Details |
| Thickness Options | 0.5mm / 0.8mm / 1.0mm / 1.5mm / 2.0mm |
| Width Options | 500mm / 1000mm / 1500mm |
| Length Options | 50m / 100m / 150m |
1. Raw Material Preparation
Purchase raw materials.
Use high-quality low-density polyethylene (LDPE) as the main raw material.
2. Extrusion Foaming Molding
Melting and extrusion system: Adopt a twin-screw extruder with zone temperature control.
Zone 1: 120℃ (preheating)
Zone 2: 150℃ (melting)
Zone 3: 180℃ (plasticizing)
Maintain melt pressure at 15-20MPa.
Control extruder speed at 50-70rpm.
Bubble forming process: Molten material forms two layers of film through a special mold.
The lower film forms bubble prototypes via vacuum adsorption.
Heat sealing and compounding are done before bubbles fully cool.
Control cooling roller temperature at 15-20℃.
3. Subsequent Processing
Corona treatment: Treatment power 4-6kW; Treatment speed 10-15m/min.
Winding and slitting: Adopt a constant tension automatic winding system.
Slitting accuracy: ±0.5mm.
Online detection system monitors thickness uniformity in real time.
Quality inspection: Check bubble integrity for each roll.
Conduct random drop tests (1m height, 3 consecutive times).
1. Electronic Product Packaging
LCD display devices: Suitable for transportation protection of 32-85 inch LCD screens.
Form a buffer layer between the screen surface and the packaging box.
Anti-static type is used for sensitive displays like OLED.
Computer equipment: Buffer for internal components of server hosts.
Overall wrapping protection for laptops.
2. Glass Product Protection
Building glass, daily-use glass, and glass furniture for transportation packaging.
Separate wrapping for kitchen utensils.
Filling and buffering for lighting products.
3. Industrial Manufacturing Field
Precision instruments, auto parts, and lamp assembly packaging.
Transportation protection for dashboards.
Protection for precision sensors and automation equipment packaging.
4. Crafts and Special Items
Artwork protection: Full wrapping for sculptures.
Liner for painting transportation.
Transportation protection for antiques and cultural relics.
Musical instrument packaging and shockproofing for audio equipment.
Q1: Main functions?
A: Buffer protection during transportation, impact and vibration protection.
Q2: How to choose bubble size?
A: Select 6-10mm for lightweight items and 20-30mm for heavy ones.
Q3: Features of anti-static type?
A: Anti-static, protect sensitive components.
