Compatible with diverse materials including metals, PVC, and ABS, it is widely used for equipment nameplate installation, appliance component fixation, and office applications. Leveraging Yongda's mature adhesive production system, the tape ensures uniform adhesion, easy peeling, and customizable dimensions to meet both industrial production line efficiency and small-batch requirements. Customers nationwide interested in this product are welcome to inquire about pricing.
1. Core Adhesive Performance: The oil-based adhesive formula delivers exceptional initial tack, enabling instant positioning upon contact. With a 180° peel strength of ≥8N/24mm and stable adhesion retention, it effectively prevents edge lifting and peeling in standard conditions. The adhesive withstands temperatures up to 60°C for long-term use and 80°C for short-term exposure, making it compatible with typical operating temperatures of household appliances.
2. Structural Material Characteristics: Made of high-density cotton paper, the base material is flexible and strong enough to resist tearing when manually removed. The adhesive layer is evenly coated without bubbles or overflow, and the outer layer is equipped with easy-peel release paper to protect the adhesive surface from contamination, making it convenient to use.
3. Practical Adaptability: The adhesive layer exhibits strong adhesion to common industrial materials including stainless steel, polycarbonate, ABS plastic, and PVC sheets. The cotton paper substrate allows slight bending, making it suitable for flat or slightly curved surfaces. It supports both manual scissors cutting and mechanical batch cutting, with flexible size adjustment.
1. Strong scene adaptability: The Yongda 8513 Double Sided Tape can be used for both industrial and office needs. It can be used as the nameplate of machine tools in the workshop and the evaporation of refrigerators, and also meet the daily needs of sticking files and accessories, realizing the double advantages of "industrial reliability + civil convenience".
2. Efficient operation with low noise: The cotton paper substrate has uniform tearing resistance, easy to tear and cut, no sharp breaking sound, suitable for quiet office environment; in the production line, workers can quickly complete the stripping and sticking, the single roll use efficiency is 15% higher than ordinary tape.
3. Cost-Quality Balance: Utilizing domestically sourced premium raw materials, we ensure reliable bonding while maintaining cost efficiency, ideal for small to medium batch purchases. With Yongda's standardized production process, each batch maintains performance accuracy within ±5%, ensuring consistent quality.
4. High application convenience: No professional tools required, manual cutting and pasting can be completed; the release paper adheres moderately to the adhesive layer, eliminating issues like "adhesive sticking to the release paper" or "adhesive residue" during peeling, reducing rework rate.
1. Material Selection and Formula: Utilizing 70g high-weight cotton paper substrate, premium petroleum-based adhesive materials, and specialized stabilizers, we formulate adhesive solutions with precision targeting "high initial adhesion + 60°C temperature resistance". Each batch undergoes pre-testing for viscosity and adhesion performance.
2. Adhesive preparation and substrate treatment: The Yongda 8513 Double Sided Tape adhesive raw materials are polymerized by stirring at a constant temperature for 6 hours to form oil adhesive, and then filtered through 400 mesh filter to remove impurities. The cotton paper substrate is dust-removed and surface activated to improve the bonding strength between the adhesive layer and the substrate and avoid delamination in the later stage.
3. Precision Coating and Lamination: Using precision coating equipment, apply oil-based adhesive uniformly to both sides of the cotton paper with a thickness of 35μm, with an error tolerance of ±3μm. After precise alignment with the release paper, laminate through a 60℃ constant-temperature pressing process to ensure a bubble-free adhesive layer and tight adhesion.
4. Maturation Testing and Packaging: Semi-finished products are stored in a 45℃ maturation chamber for 48 hours to stabilize the adhesive layer properties. Samples are then tested for peel strength, temperature resistance, and appearance. Non-conforming products are immediately discarded, while qualified products are rolled and labeled before storage.
1. Appearance and identification: The adhesive layer is transparent, and the cotton paper substrate is white. The surface is smooth without impurities and adhesive spots.
2. Specifications: The standard model is a 18mm×5.5m/ roll, suitable for small nameplates and daily application. Custom production is supported with adjustable widths ranging from 6mm to 500mm and lengths from 5m to 100m, meeting diverse application requirements.
3. Core performance parameters: Long-term temperature resistance ≥60℃, short-term temperature resistance ≥80℃, 180° peel strength ≥8N/24mm, initial adhesion ≥18-gauge steel ball standard, holding adhesion>48h/24×24mm, total thickness typically 100μm±10μm.
4. Tear-off method: Supports multiple tear-off methods including easy tear-off, cross-cut, and straight-cut. The edges are neatly torn by hand, and small size cutting can be completed without the need for cutting tools.
1. Industrial Manufacturing: Primarily used for labeling and securing equipment in production facilities, including machine nameplates in workshops, parameter plaques for assembly lines, and warehouse shelf labels. The flexible cotton paper substrate also enables temporary positioning and auxiliary bonding for stamped parts and metal components, thereby enhancing assembly efficiency.
2. Home appliance manufacturing: The process involves securing internal components for appliances such as refrigerators, washing machines, and air conditioners. This includes bonding evaporator sheets to refrigerators, sealing air conditioner filter frames, and attaching control panels to appliance casings. The 60°C long-term temperature resistance ensures compatibility with standard operating temperatures.
3. Electronic and digital applications: For securing miniature electronic components, such as LED strip installation, film switch integration, and electronic dictionary key panel bonding. The adhesive layer is corrosion-resistant with stable adhesion, meeting the precision bonding requirements for electronic components.
4. Advertising & Signage: Ideal for installing small indoor/outdoor signs and badges, including mall wayfinding signs, office nameplates, and exhibition display text stickers. Strongly adheres to materials like PVC, acrylic, and metal, and is suitable for small curved surfaces.
5. Daily office and household use: Suitable for corporate document binding, archive bag sealing, and office stationery assembly. Also works well for home decor, photo wall mounting, and compact storage box construction. Easy to use without leaving adhesive residue on surfaces.
Q1: Can it stick to the stainless steel nameplate and resist wind and rain when used outdoors?
Answer: Yes. The adhesive layer has strong adhesion to stainless steel and basic moisture resistance. It can resist wind and rain erosion for short-term outdoor use (within 1 year). For long-term outdoor use, it is recommended to combine with sealant to enhance protection.
Q2: Is it easy to cut edges when cutting manually?
Answer: It is not easy to cut edges. The high-density cotton paper base material is uniform, and it can be cut with ordinary scissors to get neat edges without professional cutting tools, which is suitable for small batch manual operation.
Q3: Will the surface of the object be damaged if you remove the adhesive after changing its position?
Answer: Most materials won't cause damage. Peel off slowly within 12 hours after application, and the adhesive layer will not be easily left behind. If the application time is too long, you can first use a warm towel to soften the adhesive surface before peeling off, so as to reduce the risk of surface damage.
