White Double Sided Duct Tape

This White Double Sided Duct Tape is specifically designed for applications requiring high mechanical stress resistance, including base layer fixation in carpet installation, pipe wrapping in industrial settings, and container sealing for logistics vehicles. The fiber cloth substrate allows it to adapt to slight surface irregularities while delivering exceptional tear resistance.

We can provide free samples for customers to test. For confirmed orders, we will arrange production according to the agreed delivery date, and provide necessary technical support and quality tracking services throughout the whole process.

Product Features

1. Base Structure

Constructed with high-strength polyester/cotton blend fabric, this material delivers exceptional tensile strength and tear resistance.

Double-sided uniform coating of modified acrylic pressure-sensitive adhesive, adhesive layer thickness 0.15±0.02mm

2. Mechanical Properties

180° peel strength (on stainless steel): 35-50 N/25mm

Tensile strength: ≥120 N/cm

Extension rate: ≤15%

Adhesion:>72h/1kg (23℃, 50%RH)

3. Environmental Adaptability

Temperature range: -30℃ to 100℃

Weather resistance: After 500h UV aging test, the bonding strength retention rate is>80%

Solvent resistance: can resist the erosion of common oils, acids and alkali solutions

4. App Features

The dense substrate structure effectively prevents adhesive penetration and eliminates residue during unwinding.

Can replace mechanical fasteners to suspend heavy objects (load capacity ≥20kg/25mm²)

Support manual tearing or mechanical cutting for on-site construction

5. Security Certification

Complies with EU RoHS Directive requirements

Product Superiority

1. Structural Reliability Advantage

The fabric fiber substrate has a tensile strength of ≥120N/cm, outperforming conventional substrates by over 60%

The cross-knitting technique ensures uniform strength in both warp and weft directions, with tear resistance improved by 50%

The double-sided adhesive layer thickness tolerance is controlled at ±0.02mm to ensure bonding stability.

2. Engineering Applicability Advantages

Operating temperature range of-30℃ to 100℃, covering most industrial environmental requirements

The adhesion strength remains above 80% after 500 hours of uv aging test, as verified by laboratory

The substrate density reaches 280g/m², effectively blocking adhesive penetration and preventing damage when unwinding

3. Construction Efficiency Advantage

Support manual tearing without special tools, reducing construction costs

The initial adhesion force is 15N/25mm, enabling instant positioning and fixation.

Adhesion lasts over 72 hours (1kg load), ensuring long-term bonding reliability

4. Economic Advantages

Service life of more than 5 years, significantly reducing maintenance frequency

It can replace traditional processes such as screw welding and save 30% of installation cost

Standard 50-meter single roll packaging reduces replacement frequency and improves work efficiency

5. Quality Assurance Advantages

Provide third-party test reports for each batch

The production line features online tension control to ensure the flatness of the coil.

Supports meter calibration and provides accurate dosage calculation

This White Double Sided Duct Tape has passed SGS testing and certification, and meets RoHS environmental requirements.

Product Processing

1. Pre-treatment of Substrate

Fabric selection: High-strength polyester/cotton blended fabric (common weight range 200-300 g/m²) is selected. The base material must pass tensile strength (≥120 N/cm) and elongation at break (≤15%) tests before entering the factory.

Surface cleaning: Remove grease and dust from the surface of the fiber cloth by high-pressure plasma cleaning or solvent wiping to improve the impregnation of the adhesive.

Corona treatment: Corona activate the substrate to increase the surface tension to more than 50 dyn/cm to ensure the adhesion of the adhesive.

2. Adhesive Preparation and Coating

Emulsion preparation:

Solid acrylic resin is mixed with organic solvent. Ethyl acetate is one example. Or use water-based acrylic emulsion with no solvent. Adjust the solid content to 40%-60%.

Precision coating:

Use a comma scraper or micro-embossed applicator. Apply the adhesive evenly to one side of the fiber cloth. Keep the thickness within ±0.02 mm.

Change the coating speed based on the adhesive viscosity. The standard speed is 10-30 meters per minute.

Pre-drying:

The coated material goes through a hot air zone. The temperature is 60-80°C. This removes most of the solvent for solvent-based adhesive. It removes most of the water for water-based adhesive.

3. Composite and Curing

First lamination:

Put a release film on the semi-cured adhesive. The film is usually PET. It has a peel strength of 5-10 g/in. Press with rollers. This makes sure the film sticks well. No bubbles form.

Reversed coating and lamination:

Turn the material over. Do the coating and pre-drying again on the other side. Then add release paper to the second adhesive side. The paper can be kraft paper. Its weight is 80-120 g/m².

Primary curing:

The full tape goes into a curing chamber. It stays there at 40-50°C for 48-72 hours. The adhesive fully cross-links. It reaches its final bonding strength.

4. Post-processing and quality control

Cut and Re-roll:

The wide-format master roll (standard width 1.2-1.6 m) is cut into customer-specified widths (e.g., 10 mm, 15 mm, 50 mm) using a rotary blade slitter.

During the unrolling process, the meter calibration and tension control are performed simultaneously to ensure neat winding.

Online inspection: The CCD camera automatically detects surface defects of the tape (such as uneven adhesive layer, bubbles, impurities).

Performance sampling: each batch is sampled and tested for key parameters such as stripping strength, adhesion, and temperature resistance. Only after meeting the standards can it be packaged.

5. Packaging and Storage

Inner packaging: Each roll of White Double Sided Duct Tape is individually wrapped in OPP film to prevent dust contamination.

Outer packaging: PE wrapping film is added inside the carton to prevent moisture, and the box is labeled with specifications, batch number, length (in meters), and production date.

Storage conditions: 15-30℃, 40%-60% humidity, avoid direct sunlight.

Product Specifications

FAQ

Q1: How to get samples?

A: We provide free samples (up to 3 specifications, total length ≤10 meters) and send within three business days.

Q2: Do you support customization?

A: Customizable support width (5-1000mm), adhesive layer thickness (0.10-0.25mm/ surface), release material, and flame retardant grade. Specific minimum order quantity and delivery time are subject to confirmation.

Q3: How about weather resistance?

A: Maintains ≥82% strength after 500-hour UV exposure, withstands temperatures from-30°C to 100°C, and resists corrosion from oils and dilute acids/alkalis.

Q4: How long is the delivery time for batch orders?

A: Standard specifications will be shipped within 7 working days, while customized specifications take 10-15 working days. We provide progress tracking, and expedited arrangements can be arranged upon request.
